Features and specifications:

What Is a 608 bearing?

The most common standardized ball bearing size is the 608 series. The 608 series is the original standard ball bearing. In the 608 series, the ball bearing typically consists of optional closures, inner race, outer race, balls, and a ball retainer.

The ABEC rating is graded in five tiers of 1, 3, 5, 7, and 9 ratings, where the higher the rating, the tighter the tolerances of the bearing. Ball bearings that have a high ABEC system rating are used for high precision applications such as the aerospace industry or surgical equipment, and lower ABEC graded ball bearings are used for more everyday bearing applications. ABEC ratings also reflect the relative prices of ball bearings; the higher the grading, the more expensive the ball bearings.

Bearing Specifications (Metric)

Bearing Type: Sealed
Bore Dia (d): 8.000 mm
Outer Dia (D): 22.000 mm
Width (B): 7.000 mm
Radius (min) (rs): 0.30 mm
Dynamic Load Rating (Cr): 2,799 N
Static Load Rating (Cor): 1,103 N
Max Speed (Grease): 34,000 rpm
Max Speed (Oil): 40,000 rpm
Max. Shaft Shoulder Dia. Inner (Ui): 10.5 mm
Min. Housing Shoulder Dia., Outer (Uo): 19.03 mm
Ball Qty: 7
Ball Dia (Dw): 3.969 mm
Weight (g): 12.80 grams
Precision: ABEC-5
Standard Clearance: C0/(K25)
Material: 52100 Chrome SteelMore about the 608RS bearing
